Axis P5514 User Manual

AXISP55NetworkCameraSeries
SDCardSlot
NO NO
NO
TICE TICE
TICE
•RiskofdamagetoSDcard.Donotusesharptoolsorexcessiveforcewheninserting
orremovingtheSDcard.
•Riskofdataloss.Topreventdatacorruption,theSDcardshouldbeunmountedbefore
removal.Tounmount,gotoSetup>SystemOptions>Storage>SDCardandclick
Unmount.
ThisproductsupportsSD/SDHC/SDXCcards(notincluded).
ForSDcardrecommendations,seewww.axis.com
Multi-ConnectorCable(soldseparately)
WhenconnectingexternalequipmenttotheAxisproduct,amulti-connectorcable(availablefrom
Axis)isrequiredinordertomaintaintheproduct’sIPrating.Themulti-connectorcablecanbe
purchasedfromyourAxisreseller.
Connectthemulti-connectorcabletotheproduct’smulti-connector.Tolocatethemulti-connector,
seeHardwareOverviewonpage9.Thecableprovidesthefollowingconnectors:
Powerconnector-3-pinterminalblockusedforpowerinput.Seeimagebelow.UseaSafetyExtra
LowVoltage(SELV)compliantlimitedpowersource(LPS)witheitheraratedoutputpowerlimited
to≤100Woraratedoutputcurrentlimitedto≤5A.
Audioin(pink)-3.5mminputforamonomicrophone,oraline-inmonosignal(leftchannelis
usedfromastereosignal).
Audioout(green)-3.5mmoutputforaudio(linelevel)thatcanbeconnectedtoapublicaddress
(PA)systemoranactivespeakerwithabuilt-inamplier.Astereoconnectormustbeusedforthe
audioout.
I/Oterminalconnector-Usewithexternaldevicesincombinationwith,forexample,tampering
alarms,motiondetection,eventtriggering,timelapserecordingandalarmnotications.Inaddition
tothe0VDCreferencepointandpower(DCoutput),theI/Oconnectorprovidestheinterfaceto:
•Digitaloutput—ForconnectingexternaldevicessuchasrelaysandLEDs.
ConnecteddevicescanbeactivatedbytheVAPIX®ApplicationProgramming
Interface,outputbuttonsontheLiveViewpageorbyanActionRule.Theoutput
willshowasactive(shownunderSystemOptions>Port&Devices>Port
Status)ifthealarmdeviceisactivated.
•Digitalinput—Analarminputforconnectingdevicesthatcantogglebetween
anopenandclosedcircuit,forexample:PIRs,door/windowcontacts,glass
breakdetectors,etc.Whenasignalisreceivedthestatechangesandtheinput
becomesactive(shownunderSystemOptions>Port&Devices>PortStatus).
13
ENGLISH

Axis P5514 Specifications

General

Type	IP security camera
PTZ control	Yes
Certification	EN 55022 Class A, EN 61000-3-2, EN 61000-3-3, EN 55024, EN 61000-6-1, FCC Part 15 Subpart B Class A, ICES-003 Class A, VCCI Class A, C-tick AS/NZS CISPR 22 Class A, KCC KN22 Class A, KN24, IEC/EN/UL 60950-1, IEC 60068-2, IEC 60721-4-3 Class 3K3, 3M3 +B38 IEC/EN/UL 60950-22
Languages support	CHI (SIMPL), ESP, FRE, GRE, ITA, JPN, KOR, POR, RUS
Placement supported	Indoor
Connectivity technology	Wired
Form factor	Dome
Mounting type	Desk/Ceiling
Product color	White
Housing material	Polycarbonate (PC)
International Protection (IP) code	IP66
Maximum resolution	1280 x 720 pixels
Supported video modes	720p
Video formats supported	AVC, H.264, MPEG4
Image quality adjustment	Brightness, Contrast, Sharpness
Supported graphics resolutions	320 x 180, 1280 x 720 (HD 720)
Pan speed	360 °/sec
Tilt angle range	1.8 - 100 °
Minimum illumination	0.7 lx
Sensor type	CMOS
Optical sensor size	1/2.3 \
Digital zoom	10 x
Optical zoom	12 x
Focal length range	3.8 - 42.9 mm
Alert notification type	E-mail, Text alert message
Built-in HDD	No
Flash memory	256 MB
Internal memory	512 MB
Compatible memory cards	SD, SDHC, SDXC
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.1af, IEEE 802.3at
Supported network protocols	IPv4/v6, HTTP, HTTPSa , SSL/TLSa , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnPTM, SNMP v1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SFTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH
Audio system	2-way
Voice codecs	G.711, G.726
Built-in microphone	-
Audio formats supported	LC-AAC
Power source type	PoE
Power consumption (max)	12.95 W
Power consumption (typical)	6.9 W
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	15 - 100 %

Weight and Dimensions

Weight	1100 g
