AXIS P5534 PTZ Dome Network Camera
Hardware overview
• ConnectingtoAXISInternetDynamicDNSService. Seepage 40. To connect, press and hold the button for
about 3 seconds.
• Resetting the product to factory default settings. See page 46.
Restart b utton - Press to restart the product.
Multi-connector - Terminal connector for connecting e xternal equipment:
• Audio equipment
• Input/Output (I/O) devices
• AC/DC power supply
When connecting external equipment, a multi-connector cable (available from Axis) is required in order to maintain the product’s IP
rating, see Multi-Connector Cable (sold separately), on page 47.
LED indicators
Color
Indication
Unlit
Connection and normal operation
Amber
Steady during startup. Flashes during firmware upgrade.
Amber/red Flashes ambe r/red if network connection is unavailable or lost.
Red Flashes red for firmware up grade failure.
Green Shows steady green for 10 seconds for normal operation after restart.
Note
• The Status LED can be configured to flash while an event is active.
Midspan LED indicators
LED
Color
Indication
Unlit No camera connected.
Green Steady when camera connected, normal operation.
Green, fl
ashing
Slow flas
h w hen over current or short circuit condition on the por t.
Port
Green, flashing
Fast flash when input voltage is out of range or other internal error.
AC input Green Steady when AC power connected.
