AXIS P5534 PTZ Dome Network Camera
Accessing the product
Accessing the product
To install the Axis product, refer to the Installation Guide supplie d with the product.
The product can be used with most operating systems and bro wsers. The recommended browsers are Internet Explorer with Windows,
Safari with Macintosh and Firefox with other operating systems. See Technical Specifications, on page 54.
Note
• To view streaming video in Internet Explorer, allow installation of AXIS Media Control (AMC) when prompted.
• QuickTime
TM
is also supported for viewing H.264 streams and for audio.
• If your computer restricts the use of additional software compo nents, the product can b e configured to use a Java
applet for viewing Motion JPEG.
• The Axis p roduct includes (1) H.264 decoder license for viewing video streams an d (1) AAC audio license. These licenses are
automatically installed with AMC. The administrator can dis able the installation of the decoders, to prevent installation of
unlicensed cop ies.
Access from a browser
1. Start a browser (Internet Explorer, Firefox, Safari).
2. Enter the IP address or host name of the Axis product in the browser’s Location/Address field. To access the product from a
Macintosh computer (Mac OS X), click on the Bonjour tab and s elect the product from the drop-down list.
If you do not know the IP address, use AXIS IP Utility to locate the product o n the network. For more informa tion on how to
discover and assign an IP address, refer to the Installation Guide.
3. Enter your user name and password. If this is the firs t time the p roduct is accessed, the root password must first be
configured; for instructions see Set the root password, on page 8 .
4. The product’s Live View page appears in your browser.
Note
The layout of the Live View page may have been customized to meet specificrequi
rements. Consequently, some of the
examples and functions featured here may differ from those displayed in your own Live View page.
7

Axis P5534 Specifications

General

Maximum resolution	1280 x 720 pixels
Video formats supported	H.264
Pan range	0 - 360 °
Tilt angle range	0 - 180 °
Camera shutter speed	1/10000 - 1/4 s
Minimum illumination	0.74 lx
Sensor type	CCD
Optical sensor size	1/3 \
Digital zoom	18 x
Focal length range	4.7 - 84.6 mm
Video motion detection	Yes
Supported network protocols	IPv4/v6, HTTP, HTTPS, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Power source type	PoE
Ethernet LAN (RJ-45) ports	1
Dimensions (WxDxH)	183 x 183 x 195 mm
Certification	EN 55022 Class B, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, EN 55024, FCC Part 15 Subpart B, Class B, ICES-003 Class B, VCCI Class B, C-tick AS/NZS CISPR 22, EN 60950-1, KCC Class B, IEC 60721-4-3 Class 3K3, 3M3, EN/IEC 60068-2
Processor model	ARTPEC-3
Flash memory	128 MB
Internal memory	256 MB

Weight and Dimensions

Weight	2300 g
