Axis Q1604 E User Manual

LowbatterypoweraffectstheoperationoftheRTC,causingittoreset
ateverypower-up.Alogmessagewillappearwhenthebatteryneeds
replacing.
Thebatteryshouldnotbereplacedunlessrequired,butifthebattery
doesneedreplacing,contactAxissupportatwww.axis.com/techsupfor
assistance.
WARNING
•Riskofexplosionifthebatteryisincorrectlyreplaced.
•Replaceonlywithanidenticalbatteryorabatterywhichis
recommendedbyAxis.
•Disposeofusedbatteriesaccordingtolocalregulationsor
thebatterymanufacturer'sinstructions.
DisposalandRecycling
Whenthisproducthasreachedtheendofitsusefullife,disposeof
itaccordingtolocalrawsandregulations.Forinformationabout
yournearestdesignatedcollectionpoint,contactyourlocalauthority
responsibleforwastedisposal.Inaccordancewithlocallegislation,
penaltiesmaybeapplicableforincorrectdisposalofthiswaste.
Europe
Thissymbolmeansthattheproductshallnotbedisposedof
togetherwithhouseholdorcommercialwaste.Directive2012/19/EU
onwasteelectricalandelectronicequipment(WEEE)isapplicablein
theEuropeanUnionmemberstates.Topreventpotentialharmto
humanhealthandtheenvironment,theproductmustbedisposed
ofinanapprovedandenvironmentallysaferecyclingprocess.For
informationaboutyournearestdesignatedcollectionpoint,contact
yourlocalauthorityresponsibleforwastedisposal.Businessesshould
contacttheproductsupplierforinformationabouthowtodispose
ofthisproductcorrectly.
ThisproductcomplieswiththerequirementsofDirective2011/65/EU
ontherestrictionoftheuseofcertainhazardoussubstancesin
electricalandelectronicequipment(RoHS).
China
Thisproductcomplieswiththerequirementsofthelegislative
actAdministrationontheControlofPollutionCausedbyElectronic
InformationProducts(ACPEIP).
ContactInformation
AxisCommunicationsAB
Emdalavägen14
22369Lund
Sweden
Tel:+46462721800
Fax:+4646136130
www.axis.com
Support
Shouldyourequireanytechnicalassistance,pleasecontactyourAxis
reseller.Ifyourquestionscannotbeansweredimmediately,your
resellerwillforwardyourqueriesthroughtheappropriatechannelsto
ensurearapidresponse.IfyouareconnectedtotheInternet,youcan:
•downloaduserdocumentationandsoftwareupdates
•ndanswerstoresolvedproblemsintheFAQdatabase.Search
byproduct,category,orphrase
•reportproblemstoAxissupportstaffbyloggingintoyourprivate
supportarea
•chatwithAxissupportstaff(selectedcountriesonly)
•visitAxisSupportatwww.axis.com/techsup/
LearnMore!
VisitAxislearningcenterwww.axis.com/academy/forusefultrainings,
webinars,tutorialsandguides.

Axis Q1604 E Specifications

General

Total megapixels	1.4 MP
Maximum resolution	1400 x 1050 pixels
Supported video modes	720p
Video formats supported	H.264, M-JPEG
Analog signal format system	NTSC
Camera shutter speed	1/29500 s
Minimum illumination	0.1 lx
Field of view (FOV) angle	100 °
Sensor type	CMOS
Optical sensor size	1/3 \
Optical zoom	- x
Focal length range	2.8 - 8 mm
Normal focusing range	0.3 m
Video motion detection	Yes
Built-in HDD	-
Compatible memory cards	SD, SDHC
LED type	IR
Type	IP security camera
Placement supported	Outdoor
Connectivity technology	Wired
Form factor	Dome
Mounting type	Wall
Product color	White
International Protection (IP) code	IP66
Interface	RJ-45
Ethernet LAN (RJ-45) ports	1
Audio system	2-way
Signal-to-Noise Ratio (SNR)	40 dB
Cabling technology	10/100Base-T(X)
Power source type	PoE
AC input frequency	50 - 60 Hz
Cables included	LAN (RJ-45)
Operating temperature (T-T)	-40 - 50 °C
Compatible operating systems	Windows 7/Vista/XP
F-number (relative aperture)	1.2

Weight and Dimensions

Depth	405 mm
Width	162 mm
Height	142 mm
Weight	3200 g
