AXISQ1604-ENetworkCamera

Events

•Day/NightVisionMode–Setdaymode(IRcutlteron)ornightmode(IRcutlteroff).

•OutputPort–ActivateanI/Oporttocontrolanexternaldevice.

•OverlayText–Displayanoverlaytext.See.

•PlayAudioClip–SeeAudioClips,onpage28.

•RecordVideo–Recordvideotoaselectedstorage.

•SendImages–Sendimagestoarecipient.

•SendNotications–Sendanoticationmessagetoarecipient.

•SendVideoClip–Sendavideocliptoarecipient.

•StatusLED–FlashtheLEDindicator.Thiscanforexamplebeusedtovalidatetriggerssuchasmotiondetectionduring

productinstallationandconguration.

SettingUpanActionRule

Anactionruledenestheconditionsthatmustbemetfortheproducttoperformanaction,forexamplerecordvideoorsendan

emailnotication.Ifmultipleconditionsaredened,allofthemmustbemettotriggertheaction.

Thefollowingexampledescribeshowtosetupanactionruletorecordvideotoanetworkshareifthereismovementinthe

camera’seldofview.

Setupmotiondetectionandaddanetworkshare:

1.GotoDetectors>MotionDetectionandcongureamotiondetectionwindow.Seepage33

2.GotoSystemOptions>Storageandsetupthenetworkshare.Seepage51.

Setuptheactionrule:

1.GotoEvents>ActionRulesandclickAdd.

2.SelectEnableruleandenteradescriptivenamefortherule.

3.SelectDetectorsfromtheTriggerdrop-downlist.

4.SelectMotionDetectionfromthedrop-downlist.Selectthemotiondetectionwindowtouse.

5.Optionally,selectaScheduleandAdditionalconditions.Seebelow.

6.UnderActions,selectRecordVideofromtheTypedrop-downlist.

7.SelectaStreamproleandconguretheDurationsettingsasdescribedbelow.

8.SelectNetworkSharefromtheStoragedrop-downlist.

Toaddadditionalcriteria,selecttheAdditionalconditionsoptionandaddadditionaltriggers.Topreventanactionfrombeing

triggeredrepeatedly,aWaitatleasttimecanbeset.Enterthetimeinhours,minutesandseconds,duringwhichthetrigger

shouldbeignoredbeforetheactionrulecanbeactivatedagain.

TherecordingDurationofsomeactionscanbesettoincludetimeimmediatelybeforeandaftertheevent.SelectPre-triggertime

and/orPost-triggertimeandenterthenumberofseconds.WhenWhiletheruleisactiveisenabledandtheactionistriggered

againduringthepost-triggertime,therecordingtimewillbeextendedwithanotherpost-triggertimeperiod.

Formoreinformation,seetheonlinehelp

Questions and Answers:

Need help?

Do you have a question about the Axis Q1604 E and is the answer not in the manual?

Axis Q1604 E Specifications

General

Total megapixels	1.4 MP
Maximum resolution	1400 x 1050 pixels
Supported video modes	720p
Video formats supported	H.264, M-JPEG
Analog signal format system	NTSC
Camera shutter speed	1/29500 s
Minimum illumination	0.1 lx
Field of view (FOV) angle	100 °
Sensor type	CMOS
Optical sensor size	1/3 \
Optical zoom	- x
Focal length range	2.8 - 8 mm
Normal focusing range	0.3 m
Video motion detection	Yes
Built-in HDD	-
Compatible memory cards	SD, SDHC
LED type	IR
Type	IP security camera
Placement supported	Outdoor
Connectivity technology	Wired
Form factor	Dome
Mounting type	Wall
Product color	White
International Protection (IP) code	IP66
Interface	RJ-45
Ethernet LAN (RJ-45) ports	1
Audio system	2-way
Signal-to-Noise Ratio (SNR)	40 dB
Cabling technology	10/100Base-T(X)
Power source type	PoE
AC input frequency	50 - 60 Hz
Cables included	LAN (RJ-45)
Operating temperature (T-T)	-40 - 50 °C
Compatible operating systems	Windows 7/Vista/XP
F-number (relative aperture)	1.2
