AXISQ1604-ENetworkCamera
TechnicalSpecications
Note
TheI/Oconnectorisconnectedtothehousing(fan/heater)ondelivery.Inthecaseofafanorheatererror,aninputsignal
willbetriggeredinthecamera.Setupanactionruleinthecameratocongurewhichactionthesignalshalltrigger.For
informationabouteventsandactionrules,seeEvents,onpage37.
FunctionPinNotes
Specications
0VDC(-)
1
0VDC
DCoutput
2
Canbeusedtopowerauxiliaryequipment.
Note:Thispincanonlybeusedaspowerout.
3.3VDC
Maxload=50mA
DigitalInput
3
Connecttopin1toactivate,orleaveoating(unconnected)
todeactivate
0tomax40VDC
DigitalOutput
4
Connectedtopin1whenactivated,oating(unconnected)
whendeactivated.Ifusedwithaninductiveload,e.g.arelay,
adiodemustbeconnectedinparallelwiththeload,for
protectionagainstvoltagetransients.
0tomax40VDC,opendrain,
100mA
3.3 V max 50 mA
1
2
3
4
PowerConnector
2-pinterminalblockforpowerinput.
UseaSafetyExtraLowVoltage(SELV)
compliantlimitedpowersource(LPS)
witheitheraratedoutputpower
limitedto≤100Woraratedoutput
currentlimitedto≤5A.
DCpowerinput
