AXISQ1932–EThermalNetworkCamera
Howtoconfiguretheliveviewwindow
OutputButtons
ExternalI/OdevicesconnectedtotheAxisproduct’soutputportscanbecontrolleddirectlyfromtheLiveViewpage.
Note
ToenablethissettingatleastoneI/Oportmustbeconguredasanoutputport.SeeI/OPortsonpage47.
TodisplayoutputbuttonsintheLiveViewpage:
1.GotoSetup>LiveViewCong.
2.UnderOutputButtons,selectthetypeofcontroltouse:
-Pulseactivatestheoutputforadenedperiodoftime.Thepulsetimecanbesetfrom1/100secondto60
seconds.
-Active/Inactivedisplaystwobuttons,oneoreachaction.
Toconguretheactiveandinactivestates,gotoSystemOptions>Ports&Devices>I/OPortsandsettheport’sNormalstate.
FormoreinformationaboutI/Oports,seeI/OPortsonpage47.
Note
AnAxismulticableisrequiredwhenconnectingexternalI/OdevicestotheAxisproduct.SeeMulticableconnectorsonpage55
23
