AXISQ1932–EThermalNetworkCamera

Technicalspeciﬁcations

ControlButton

Forlocationofthecontrolbutton,seeHardwareoverviewonpage6.

Thecontrolbuttonisusedfor:

•Resettingtheproducttofactorydefaultsettings.Seepage49.

•ConnectingtoanAXISVideoHostingSystemservice.Seepage41.Toconnect,pressandholdthebuttonforabout3

secondsuntiltheStatusLEDashesgreen.

•ConnectingtoAXISInternetDynamicDNSService.Seepage41.Toconnect,pressandholdthebuttonforabout3seconds.

Connectors

Multicableconnectors

WhenconnectingexternalequipmenttotheAxisproduct,anAxismulticableisrequiredinordertomaintaintheproduct’sIPrating.

TheAxismulticablecanbepurchasedfromyourAxisreseller.Tolocatethemulti-connector,seeHardwareoverviewonpage6.

Themulticableprovidesthefollowingconnectors:

Powerconnector-2-pinterminalblockusedforpowerinput.Thepolarityofthecablesdoesnotmatter.UseaSafetyExtra

LowVoltage(SELV)compliantlimitedpowersource(LPS)witheitheraratedoutputpowerlimitedto≤100Woraratedoutput

currentlimitedto≤5A.

Audioin(pink)-3.5mminputforamonomicrophone,oraline-inmonosignal(leftchannelisusedfromastereosignal).

Audioout(green)-3.5mmoutputforaudio(linelevel)thatcanbeconnectedtoapublicaddress(PA)systemoranactivespeaker

withabuilt-inamplier.Astereoconnectormustbeusedfortheaudioout.

I/Oterminalconnector-Usewithexternaldevicesincombinationwith,forexample,tamperingalarms,motiondetection,event

triggering,timelapserecordingandalarmnotications.Inadditiontothe0VDCreferencepointandpower(DCoutput),theI/O

connectorprovidestheinterfaceto:

•Digitaloutput—ForconnectingexternaldevicessuchasrelaysandLEDs.Connecteddevicescanbeactivatedbythe

VAPIX®ApplicationProgrammingInterface,outputbuttonsontheLiveViewpageorbyanActionRule.Theoutput

willshowasactive(shownunderSystemOptions>Port&Devices>PortStatus)ifthealarmdeviceisactivated.

•Digitalinput—Analarminputforconnectingdevicesthatcantogglebetweenanopenandclosedcircuit,for

example:PIRs,door/windowcontacts,glassbreakdetectors,etc.Whenasignalisreceivedthestatechangesand

theinputbecomesactive(shownunderSystemOptions>Port&Devices>PortStatus).

I/Oconnector

Powerinput

FunctionPinNotes

Specications

0VDC(-)

0VDC

DCoutput

Canbeusedtopowerauxiliaryequipment.

Note:Thispincanonlybeusedaspowerout.

12VDC

Maxload=50mA
