AXISQ60Series
InstalltheHardware
NOTICE NOTICE
NOTICE
•TheAXISproductshallbeconnectedusingashieldednetworkcable(STP).Allcables
connectingtheproducttothemidspanshallbeshielded(STP)andintendedfortheir
specicuse.Makesurethatthemidspanisproperlygrounded.Forinformationabout
regulatoryrequirements,seeRegulatoryInformation,onpage2.
•Mounttheproductwiththedomecoverfacingdownward.
•Becarefulnottoscratch,damageorleavengerprintsonthedomecoverbecausethis
coulddecreaseimagequality.Ifpossible,keeptheprotectiveplasticonthedomecover
untiltheinstallationiscomplete.
TheAxisproductcanbeinstalledwiththecablesroutedthroughoralongthewallorroof.
Readalltheinstructionsbeforeinstallingtheproduct.Someinstallationstepswouldbenetfrom
beingcompletedtogetherbecausetheyrequireremovalofthedomecover.
Ahardwareinstallationcanincludethefollowing:
•Theproductissuppliedwithacleardomecover(premounted).Asmokeddomecoveris
availableasanaccessory.Toreplacethedomecover,seepage14.
•AstandardorhighcapacitySDcard(notincluded)canbeusedtostorerecordingslocally
intheproduct.ToinstallanSDcard,seepage15.
•ToinstalltheproductusingacompatiblebracketfromAXIST91AMountingAccessories
(soldseparately),seepage15.
•Toinstallthesuppliedmidspan,seepage18.
AttachtheSunshield
Attachingthesunshieldisoptional.ThesunshieldprotectsthecameraagainstUVlightandhelps
keepthetemperatureinsidethecameradown.
1.Slidethesunshieldovertheunitholdersonthecameraunit.
2.Securethesunshieldusingthesuppliedscrews(T20).
ReplacetheDomeCover
Replacingthedomecoverisonlynecessaryifyouwanttouseasmokeddomecoverorifthe
domecoverisscratchedordamaged.Smokeddomecoversandsparecleardomecoverscanbe
purchasedfromyourAxisreseller.
1.Loosenthedomeringscrewsandremovethedomecover.
2.Removethedomebracketscrewsandremovethedomebracketandthedomecover
fromthedomering.
14
