Axis Q60 Series Installation Guide

AXISQ60Series
3.Makesuretherubbergasketisttedcorrectlyonthedomecover.
4.Alignthebulgeonthedomecoverwithoneofthelogotypesonthedomering.
5.Attachthedomebracketandthedomecovertothedomeringandtightenthescrews
(torque1.2Nm).
6.ToinstallanSDcard(notincluded),seeInstallanSDCard,onpage15.
7.Toattachthedomecovertothetopcover,alignthebulgeonthedomecoverwiththe
heateronthecameraunitandtightenthescrews(torque1.5Nm).
InstallanSDCard
ItisoptionaltoinstallastandardorhighcapacitySDcard(notincluded),whichcanbeusedfor
localrecordingwithremovablestorage.
1.Loosenthedomeringscrewsandremovethedomecover.
2.InsertanSDcard(notincluded)intotheSDcardslot.
4.Toattachthedomecovertothetopcover,alignthebulgeonthedomecoverwiththe
heateronthecameraunitandtightenthescrews(torque1.5Nm).
NOTICE NOTICE
NOTICE
Topreventcorruptionofrecordings,theSDcardshouldbeunmountedbeforeitisejected.
Tounmount,gotoSetup>SystemOptions>Storage>SDCardandclickUnmount.
BracketMount(soldseparately)
NOTICE NOTICE
NOTICE
•Theproductshallbegroundedusingagroundingwire.Makesurebothendsofthe
groundingwireareincontactwiththeirrespectivegroundingsurfaces.
•TocomplywiththeIP66-rateddesignofthecameraandmaintaintheIP66protection,
thesuppliedRJ45Push-pullConnector(IP66)shallbeused.Alternatively,usetheRJ45
IP66-ratedcablewithpremountedconnectorwhichisavailablefromyourAxisreseller.
Donotremovetheplasticnetworkconnectorshieldfromthecamera.
1.Installtheselectedbracketaccordingtotheinstructionssuppliedwiththebracket.If
drillingisrequired,makesuretousedrillbits,screwsandplugsthatareappropriatefor
thematerial.
2.ConnectsuppliedRJ45Push-pullConnector(IP66)tothenetworkcableaccordingtothe
instructionssuppliedwiththeconnector.
3.Routethenetworkcableandagroundingwirethroughtheholesinthemountingbracket.
4.Securethecamerausingthesuppliedsafetywire.
15
ENGLISH
