AXISQ6000-EMkIIPTZNetworkCamera
Specifications
Amber
Steadyforconnectiontoa10Mbit/snetwork.Flashesfornetworkactivity.
Steadyforconnectiontoa10/100Mbit/snetwork.Flashesfornetworkactivity.
UnlitNonetworkconnection.
Note
ThePowerLEDcanbeconguredtobeunlitduringnormaloperation.Tocongure,gotoSettings>System>Plaincong.
PowerLEDIndication
Green
Normaloperation.
Amber
Flashesgreen/amberduringrmwareupgrade.
MicrophonepowerLEDIndication
UnlitPhantompoweroff.
BluePhantompoweron.
Steadywhenthephantompowerisonandthemicrophoneisconnected.
Flasheswhenthephantompowerisonandthemicrophoneisdisconnected.
WirelessLEDIndication
UnlitWiredmode.
GreenSteadyforconnectiontoawirelessnetwork.Flashesfornetworkactivity.
Red
Steadyfornowirelessnetworkconnection.Flasheswhilescanningforwirelessnetworks.
Amber
Steadyorashingduringwirelessnetworkpairing.
Note
•ThetallyLEDcanbeconguredtobelitorunlitduringnormaloperation.Tocongure,gotoSettings>System>
Plaincong.
•ThetallyLEDonlyindicatesnetworktransmission.IfvideooraudioisonlytransmittedthroughHDMIorSDIthetallyLED
willbeunlit.
TallyLEDIndication
Unlit
Cameraidle.
RedActivenetworktransmissionorrecording.
SPKLED
Indication
GreenSteadygreenfornormaloperation.
Flashes(twoshortgreenashesandonelongwithoutlight)whentheimpedancehasnotbeen
calibrated.
RedFlashesredwhentheovercurrentprotectionhasbeentripped.
SDcardslot
CAUTION
Movingparts.Riskofinjury.Keepyourbodypartsawayfromtheproductwhenit’sinoperation.Disconnectfrom
powersupplybeforeinstallingorperformingmaintenanceontheproduct.
82
