AXISQ60Series
HardCeilingMount
1.Preparetheceilingforinstallationofthemountingplate.Thesupplieddrilltemplate
canbeusedtopositiontheholes.Makesuretousedrillbits,screwsandplugsthat
areappropriateforthematerial.
2.Installthemountingplate.Thearrowonthemountingplatewillalignwiththelogotype
onthecamera.
1
2
1
Mountingplate
2
Safetywire
3.Loosenthecamerabaselidscrewsandremovethecamerabaselid.
4.Securethecamerausingthesuppliedsafetywire.
5.Routeandconnectthenetworkcableandthemulti-connectorcable(soldseparately),if
applicable,tothecamera.
NOTICE NOTICE
NOTICE
•Becarefulnottodamagethecableswhenconnectingthem.
•Makesurethatthefoamgasketholesarealignedwiththecabletracksand,ifapplicable,
removethecut-outpieceforthemulti-connectorcablefromthefoamgasket.
1
2
3
1
Cableholders
2
Multi-connectorcable(soldseparately)
3
Networkcable(notincluded)
19
ENGLISH
