Axis Q6055 - Camera Hardware Overview; Connectors and Buttons

AXISQ6055PTZDomeNetworkCamera
HardwareOverview
HardwareOverview
NO NO
NO
TICE TICE
TICE
Makesurethedomeisattachedinoperationmode,otherwisefocusmaybeaffected.
1
Partnumber(P/N)&Serialnumber(S/N)
2
Networkconnector(PoE+)
3
Multi-connector
4
Dome
5
SDcardslot
6
StatusLEDindicator
7
Controlbutton
8
Powerbutton
ConnectorsandButtons
Fortechnicalspecications,seepage69.
NetworkConnector
RJ45EthernetconnectorwithPoweroverEthernetPlus(PoE+).
NO NO
NO
TICE TICE
TICE
Usethesuppliedmidspan.
NO NO
NO
TICE TICE
TICE
Theproductshallbeconnectedusingashieldednetworkcable(STP).Allcablesconnectingtheproducttothenetworkshall
beintendedfortheirspecicuse.Makesurethatthenetworkdevicesareinstalledinaccordancewiththemanufacturer’s
instructions.Forinformationaboutregulatoryrequirements,seeElectromagneticCompatibility(EMC)onpage2.
7
