AXISQ7424-RMkIIVideoEncoder
HardwareOverview
Forspecicationsofthehardwarecomponents,seeTechnicalSpecicationsonpage15.
1
LEDindicatorpower
2
LEDindicatorstatus
3
LEDindicatornetwork
4
Mountingholes
5
Videoinputconnectors
6
SDmemorycardlid
7
SDmemorycardslot
8
I/Oconnector
9
Audioconnectors
10
SFPconnector
11
RS485/RS422connector
12
Controlbutton
13
Powerconnector
14
Networkconnector(PoE)
10
