AXISQ7436VideoEncoderBlade

AXISVideoMotionDetection

Thedefaultincludeareaisasquarethatcoversthewholeimage.Clickontheicontohighlightthearea.

Usethemousetoreshapeandresizetheareasothatitonlycoversthepartoftheimageinwhichmovingobjectsshouldbedetected.

Thedefaultsquarecanbechangedtoapolygonwithupto20points(corners).

•Toaddanewpoint,clickontheincludeareaborder.Dragthepointtothedesiredposition.

•Toremoveapoint,right-clickonthepoint.

•Tomoveapoint,dragthepointtothenewposition.

•Tomovetheentireincludearea,placethemousepointerinsidethearea.Whenthepointerbecomesacross,dragthe

areatothenewposition.

•Toselecttheincludearea,clickontheborder.

Toresettheincludeareatoitsdefaultsize,clickReset.

ExcludeArea

Anexcludeareaisanareainwhichmovingobjectswillbeignored.Useexcludeareasifthereareareasinsidetheincludearea

thattriggeralotofunwanteddetectedobjects.Upto10excludeareascanbeused.

Note

Toaddandmodifyexcludeareas,InternetExplorerandAXISMediaControl(AMC)mustbeused.

Toaddanexcludearea,clickAdd.Thedefaultexcludeareaisarectangleplacedinthecenteroftheimage.Usethemouse

tomove,reshapeandresizetheareasothatitcoversthedesiredpartoftheimage.Thedefaultsquarecanbechangedtoa

polygonwithupto20points(corners).

•Tomovetheexcludearea,placethemousepointerinsidethearea.Whenthepointerbecomesacross,dragthearea

tothenewposition.

•Toaddanewpoint,clickontheexcludeareaborder.Dragthepointtothedesiredposition.

•Toremoveapoint,right-clickonthepoint.

•Tomoveapoint,dragthepointtothenewposition.

•Toselectanexcludearea,clickontheborder.

Toremoveanexcludearea,selecttheareaandthenclickRemove.

Tohighlighttheexcludeareas,clickonthe

icon.

VisualConrmation

Visualconrmationisusedtovalidatethatthesettingsarecorrect,thatis,thatallobjectsthatshouldbedetectedaredetected.

Note

Tousevisualconrmation,InternetExplorerandAXISMediaControl(AMC)mustbeused.

Whenvisualconrmationisenabled,allmovingobjectsfoundbytheapplicationwillbeencircledandfollowedbypolygons.Ared

polygonindicatesthattheobjectisfoundandisdetectedasamovingobject.Agreenpolygonindicatesthattheobjectisfoundbut

isignoredbecauseitisnotintheincludeareaorbecauseofoneoftheignorelters.

Toenablevisualconrmation:

1.SelecttheEnablevisualconrmationoption.

2.ClickSave.
