Axis Q7436 User Manual

AXISQ7436VideoEncoderBlade
HardwareOverview
HardwareOverview
Forspecicationsofthehardwarecomponents,seeTechnicalSpecicationsonpage63.
1.
BNCconnector(Videoinput,6nos.)
2.
StatusLED(6nos.)
3.
Controlbutton
4.
Restartbutton
5.
PowerLED
6.
Busconnector
ConnectorsandButtons
BusConnector
Thebusconnectorsarethephysicalinterfacestothevideoencoderchassisthatprovidepower,network,RS485,andI/Oterminal
connections.
ControlButton
Forlocationofthecontrolbutton,seeHardwareOverviewonpage6.
Thecontrolbuttonisusedfor:
•Resettingtheproducttofactorydefaultsettings.Seepage58.
•ConnectingtoanAXISVideoHostingSystemservice.Seepage50.Toconnect,pressandholdthebuttonforabout3
secondsuntiltheStatusLEDashesgreen.
•ConnectingtoAXISInternetDynamicDNSService.Seepage50.Toconnect,pressandholdthebuttonforabout3seconds.
RestartButton
Presstherestartbuttontorestarttheproduct.
6
