Chapter 1: Introduction to the Axon Dock 2
TASER Axon Dock Installation Manual
An additional bay, called the 6-bay is available. As with the individual bays, there are 3 dierent 6-bays.
One accepts Axon Body cameras and Axon Flex cameras and controllers. Another accepts Axon Body
2 and Axon Fleet cameras, and the third is designed for Axon Flex 2 cameras and controllers.
(The 6-bay for Axon Flex 2 systems is not shown here.)
A bridge adapter is used to attach the core to a bay, and to attach individual bays to each other.
CAUTION! CONNECTOR DAMAGE
Be careful when removing a bridge adapter from a bay, as damage may occur if the bridge adapter is
removed unevenly from the bay. Bridge adapters must be pulled straight out and not angled when
removed.
A locking adapter is used to help fasten a core and bays together.
6-Bay for Axon Body 2 and Axon Fleet
Cameras
6-Bay for Axon Body Cameras and Axon Flex Systems
Bridge Adapter Front Bridge Adapter Back
Locking Adapter
