Page #5 background image
AX-GMLAN11-SWC
®
5
Initializing and programming
the AX-GMLAN11-SWC (Cont)
Initializing and programming
the AX-GMLAN11-SWC (Cont)
For the steps below, the Red L.E.D. (located inside the interface, next to the
potentiometer) can only be seen while active. The interface does not need to be
opened to see the L.E.D. This is a timed process, so it would be best to read these
steps beforehand, to ensure a clear understanding of what is to be expected.
1. Turn the key (or push-to-start button) to the ignition position, the L.E.D. will turn on.
2.
Within a minute, the L.E.D. will turn off for a couple seconds, then flash slowly (up
to (16) times, indicating which radio is connected to the interface), and then turn
off. Pay close attention as to how many slow flashes there are. This will help in
troubleshooting, if need be. Refer to the L.E.D. feedback section for more information.
3. Within a few seconds the L.E.D. will turn on, and the radio will turn off.
4. Within a minute the L.E.D. will turn off, and the radio will come back on,
indicating the initialization process is successful.
Note: If the radio does not come back on within a minute, the interface is not
communicating to the vehicle. Turn the key off, check all connections, and then try
again. The interface may need to be reset at this point.
5. Immediately after the L.E.D. turns off, and the radio comes back on, the
following buttons on the steering wheel must be pressed in the exact sequence
as shown. For each button press, the L.E.D. will turn on momentarily:
Volume Up
Seek Up
Volume Up
PTT (OnStar) or MUTE
Volume Up
6. The L.E.D. will turn on after the last Volume Up button has been pressed,
indicating programming has ended.
7. Press all the buttons to ensure that they are working as intended.
8. Cycle the ignition and test again.
9. If any steps in this process failed, or was executed improperly, reset the
interface, and then resume from step 5.
Notes:
PTT (OnStar) when pressed will Mute/Attenuate the radio.
PTT (OnStar) when pressed and held for 2 seconds will activate OnStar, if applicable.
Adjusting the AX-GMLAN11-SWC
OnStar Level Adjustment
Press the OnStar button to activate it.
While OnStar is speaking, press the VOLUME UP or VOLUME DOWN button on
the steering wheel to raise or lower the OnStar level.
If the vehicle does not come equipped with steering wheel controls, locate the
Black/Yellow wire on the AX-GMLAN11-SWC harness.
While OnStar is speaking, tap the Black/Yellow wire to ground. Once the
OnStar level is set, it will stay at that level until the Black/Yellow wire is tapped
to ground again.
