PROGRAMMING THE AXDIS-TY1
For the steps below, the LED located inside the interface can only be seen while active. The
interface does not need to be opened to see the LED
• Start the vehicle.
• Connect the AXDIS-TY1 harness to the wiring harness in the vehicle.
• The LED will initially turn on solid Green, then turn off for a few seconds while it auto
detects the radio installed.
• The LED will then flash Red up to (23) times indicating which radio is connected to the interface,
and then turn off for a couple of seconds. Pay close attention to how many Red flashes there
are. This will help in troubleshooting, if need be. Refer to the LED feedback section for more
information.
• After a couple seconds the LED will turn on solid Red while the interface auto detects the
vehicle. The radio will shut off at this point. This process should take 5 to 30 seconds.
• Once the vehicle has been auto detected by the interface, the LED will turn on solid
Green, and the radio will come back on, indicating programming was successful.
• Test all functions of the installation for proper operation, before reassembling the dash.
If the interface fails to function, refer to Resetting the AXDIS-TY1.
Note:
The LED will turn on solid Green for a moment, and then turn off under normal
operation after the key has been cycled.
AUDIO LEVEL ADJUSTMENT
(amplified models only)
1. With the vehicle and radio turned on, turn the volume up 3/4 of the way.
2. With a small flat-blade screwdriver, adjust the potentiometer clockwise to raise the audio
level; counter clockwise to lower the audio level.
3. Once at a desired level, audio adjustment is complete.
