7
REV. 4/22/24 INSTAXDIS-TY1
LED Feedback: The (24) Red LED flashes
represent a different radio manufacturer for
the SWC interface to detect. For example,
if you are installing a JVC radio, the SWC
interface will flash Red (5) times, then stop.
Following is the L.E.D Feedback Legend,
which indicates the flash count of the radio
manufacturer.
Flash Count
Radio
1
Eclipse (type 1) †
2
Kenwood ‡
3
Clarion (type 1) †
4
Sony / Dual
5
JVC
6
Pioneer / Jensen
7
Alpine *
8
Visteon
9
Valor
10
Clarion (type 2) †
11
Metra OE
12
Eclipse (type 2) †
Flash Count
Radio
13
LG
14
Parrot **
15
XITE
16
Philips
17
TBA
18
JBL
19
Insane
20
Magnadyne
21
Boss
22
Axxera
23
Axxerra (type 2)
24
Alpine (type 2)
LED Feedback Legend
KEYNOTES
* If the SWC interface flashes Red (7) times, and an Alpine radio is not installed, that means there is an open connection not accounted for. Verify that the 3.5mm jack is connected to the correct
steering wheel jack/wire in the radio.
** The AXSWCH-PAR is required (sold separately). Also, the software in the radio must be rev. 2.1.4 or higher.
† If a Clarion or Eclipse radio is installed and the steering wheel controls do not function, change the radio to Clarion (type 2) or Eclipse (type 2) respectively. If the steering wheel controls still
do not function, refer to the Changing Radio Type document available at axxessinterfaces.com.
‡ If a Kenwood radio is installed and the LED feedback flashes (5) times instead of (2), manually change the radio type to Kenwood. To do this, refer to the Changing Radio Type document on
next page.
STEERING WHEEL CONTROL SETTINGS: LED FEEDBACK
