Chapter 1. Overview
 Model number
Basic
model No.
Flame
detector
Power Flame
response
Additional
function
Description
AUR890 Burner controller
F Flame rod
G AUD100/110/120 Advanced Ultraviolet Flame Detector
1 100 V AC
2 200 V AC
1 1 s max.
*1
3 3 ± 1 s
*2
*1 Flame voltage at 2 V DC
*2 Flame voltage at 3 V DC
0 None
D With inspection data
Note: The dedicated sub-base and sideboard are not provided with the AUR890 controller. Order them
separately.
 Related equipment
z Compatible flame detector (sold separately)
 Flame detector ultraviolet sensor
Model number Name Notes
AUD15C1000 Advanced ultraviolet sensor
Tube unit
Use a dedicated socket for the AUD100C/110C/120C
AUD100C100_ Advanced ultraviolet ame detector (Lead wire
model without AUD15C)
AUD15C1000, sold separately
AUD100C1000-A15 Advanced ultraviolet ame detector (Lead wire
model with AUD15C)
AUD15C1000 in package
AUD110C100_ Advanced ultraviolet ame detector (Terminal
block model without AUD15C)
AUD15C1000, sold separately
AUD110C1000-A15 Advanced ultraviolet ame detector (Terminal
block model with AUD15C)
AUD15C1000 in package
AUD120C120_ Advanced ultraviolet ame detector (1/2-inch
mounting model)
Without G1/2 adapter, AUD15C1000, sold separately
AUD120C121_ With G1/2 adapter, AUD15C1000, sold separately
_ : The box stands for one of the following codes. 0: standard product. D: with inspection record (with data).
T: tropicalization (AUD110C only). B: with inspection record (with data) and tropicalization (AUD110C only).
 Flame rod
Model number Name Notes
C7007A Flame rod holder Discontinued
C7008A Flame rod assembly Discontinued
z Optional parts (sold separately)
Model number Product name Notes
BC-R05A100 Dedicated sub-base Not required if the RA890 replacement base unit
(Q890A100) is used.
81447514-001 Connector for front wiring * Contains one
Weidmueller model number : BL3.5/11F
Compatible wire: 0.2–1.5 mm
2
(28–14 AWG)
81447514-002 Connector for front wiring *
(for right-side wiring)
Contains one
Weidmueller model number : BL3.5/11/270F
Compatible wire: 0.2–1.5 mm
2
(28–14 AWG)
81447515- 001 Side boards (2) Contains two
Not included in the sub-base
Q890A100 Base unit for RA890 replacement The mounting holes and terminal numbers are the same
as those of the sub-base (Q270A1024) of the RA890.
FSP136A100 Analog ame meter
81447519-001 Loader jack cover Contains one
81447531-001 Front connector cover Mounting screw supplied
* Used for ame voltage measurement.
