47
Chapter 7. Specifications
unit: mm
 Sub-base BC-R05A100 (sold separately)
 Sideboard 81447515-001 (sold separately)
DIN rail clamp
95
105
27
17
61
64
62.5
φ12 knockout hole φ12 knockout hole
Sub-base mounting hole
Sub-base mounting hole
M3.5 (terminal screw)
Knockout hole
Knockout hole
16
Sub-base
46.6
73.5
Sideboard
Sideboard
φ19 knockout hole
φ19 knockout hole
Sub-base
30.7
23.9
