49
Chapter 7. Specifications
unit: mm
 With the base unit (Q890A100) for RA890 replacement (purchased separately)
Sideboard (in package)
M4 ground screw
5537* 126
9.5
19
3125.5
70*
Grommet (4 places)
φ23 hole (4 places)
126
* This dimension is for a product with a date code (D/C) of 1828 or later.
The height is 8 mm less than that of a product with an earlier date code.
