Azbil C15 Quick Reference Guide

3
Analog inputControl actions
SPContinuous outputsCommunications
Key operations and displays
Setting displays
Operation displays

Some items are not displayed depending on the availability of optional functions, model number, display setup (
C73
to
C78
) and display level (
C79
).

Pressing [para] key while changing settings has the effect of canceling and moving to the next item.
*1 The parameters and numerical values registered as user functions
UF
are displayed.
*2 If no key is pressed for 3 minutes, the display automatically returns to (2) , PV display.
*3 If the [<] key is pressed while holding down the [para] key, various displys/settings can be
navigated in reverse order.
*4 Cannot be selected if ROM version 1 (
id02
) of the instrument information bank is 2.26 or
earlier.

Explanation of arrows
[para] key :
2-second press +
:
hold of [para] key

Movement through each setup menu
•
[para] key Forward movement
•
[para] key + [<] key Backward movement
Internal event 3
sub setting
Setting value
Internal event 3
main setting
Setting value
Timer remaining
time 2
Internal event 2
delay time
Internal event 2
sub setting
Setting value
Internal event 2
main setting
Setting value
[Setup] [ Event configuration ] [ DI assignment ] [ DO assignment ] [ User function ] [ Instrument information ][Lock]
[para] key
PV value
AT progress
value
Internal event 1
main setting
Setting value
CT1
Current
value
CT2
Current
value
Internal event 1
sub setting
Setting value
Timer remaining
time 1
Internal event 1
delay time
2-second press + hold of [para] key
*
2
*
4
to
(2)
(B)
to
(B)
*
4

Azbil C15 Specifications

General

Brand	Azbil
Model	C15
Category	Controller
Language	English
