Model MGR13C/MGR11U - MagneW3000 Electromagnetic FLowmeter Hyper-Fill 7
2-3-3 : Master-slave wiring
If the Hyper-Fill flowmeter is installed more than five units, Hyper-Fill flowmeters
consist of one master converter and slave converters.
To ensure accurate measurement, the magnetic interference should be negligible in the
multiple head filling machine applications.
Master-slave cable carries synchronized signal for excitation so as to minimize
magnetic interference.
Each converter should be connected with the “Master-slave” cable.
Number of units of the
detector
Number of unit of the
Master converter
Number of unit of the
Slave converter
One to four units One unit Zero
More than five units One unit One unit or more
Figure 4
Master
converter
Slave
converter
Slave
converter
Slave
converter
Master-slave cable
