4 Model MGR13C/MGR11U - MagneW3000 Electromagnetic FLowmeter Hyper-Fill
2-3 : Wiring
2-3-1 : Converter wiring
Refer to the Table 1 and perform wiring. Turn off the power during wiring.
Connect the wires to the terminals of A1 to A4, B1 to B4 and C1 to C4 at first.
After connecting wires to the terminals of A1 to A4, B1 to B4 and C1 to C4, install the
shield plate as shown in the Figure 1.
The shield plate is fixed by two screws. Refer to the following table for the screw
position.
Figure 2
Left side screw position Right side screw position
between CLKOUT- and A1 between C4 and P1-
Belt
Belt
Water-proof
cover
Water-proof
cover
Water-proof
connector
Water-proof
cover
Case
Electrode
Detector
Flow
direction
arrow
Flow
direction
arrow
