Model MGR13C/MGR11U - MagneW3000 Electromagnetic FLowmeter Hyper-Fill 5
~Note 1) Perform earth ground for the power supply (terminal E), for safety
purpose.
2) To ensure accurate measurement, connect master-slave cable between
CLKOUT+/- and CLKIN+/-.
3) Pulse output is open collector type. Make sure to connect external
power supply for the pulse output.
Table 1
Symbol Connect to Meaning
H, N, E Connect to power supply. E for
earth ground. (85 to 264V AC)
Power supply and earth
ground
A1, B1, C1,
X1, Y1
Connect to the special cable model
MGA23Wfor main unit 1
Flow rate signal
Excitation
A2, B2, C2,
X2, Y2
Connect to the special cable model
MGA23W for main unit 2
Flow rate signal
Excitation
A3, B3, C3,
X3, Y3
Connect to the special cable model
MGA23W for main unit 3
Flow rate signal
Excitation
A4, B4, C4,
X4, Y4
Connect to the special cable model
MGA23W for main unit 4
Flow rate signal
Excitation
P1+, P1- Connect to pulse receiving
instrument
Pulse output for main unit 1
(Open Collector)
P2+, P2- Connect to pulse receiving
instrument
Pulse output for main unit 2
(Open Collector)
P3+, P3- Connect to pulse receiving
instrument
Pulse output for main unit 3
(Open Collector)
P4+, P4- Connect to pulse receiving
instrument
Pulse output for main unit 4
(Open Collector)
CLKOUT+,
CLKOUT-
Synchronized signal output from a
master converter and to a slave
converter
Synchronized signal output from a
slave converter to another slave
converter
Synchronized signal output
CLKIN+,
CLKIN-
Synchronized signal input from a
master converter and to a slave
converter
Synchronized signal input from a
slave converter to another slave
converter
Synchronized signal input
