User Manual
Page 54 of 68
IP Address: Set the LAN destination IP address of the forwarding rule.
Private Port: Set the service port that the wireless router provides to the LAN. The
users on the LAN send the requests to obtain the service via the port. The port
range format is “the start port - the end port”.
After finishing setting, click the Add Rule button to add the port forwarding rule.
DMZ
DMZ allows all the ports of a PC on your LAN to be exposed to the Internet. Set
the IP address of the PC to be DMZ host, so that the DMZ host will not be blocked
by the firewall and the host can realize bidirectional limitless communication with
the Internet users and servers.
Enable DMZ: Enable or disable the DMZ function.
DMZ IP Address:
Enter the IP address of the DMZ host.
After finishing setting, click the Apply
Apply Apply
Apply button to make the settings
take effect.
