User Manual
Page 57 of 68
IP Filtering
Filter Type: Select the IP filtering type in the drop-down list.
MAC/IP Filter Mode: Select the proper IP filter mode in the drop-down list.
Enabled: Enable or disable the IP filtering rule.
Rule Name: Set the name of the IP filtering rule.
IP Address: Set the IP address of the host that needs to be filtered.
Protocol: Set the protocol type for IP filtering. You may select ICMP, TCP or UDP.
Scheme: Set the time schedule for the IP filtering rule. You may select Always or
click the Add New Scheme button to set more detailed time schedule.
Port Range: Se the port range for the IP filtering rule.
After finishing setting, click the Add Rule button to add the IP filtering rule.
