General Description
© b2 electronic GmbH DHV0088 17
PDTD60-2 PDTD90-2 PDTD120-2 PDTD200-2
Article Number SH5031 SH5033 SH5034 SH5037
Operating
Voltage
sinusoidal 44 kV
rns, 60 kVpeak 64 kVrms, 90 kVpeak 85 kVrms, 120 kVpeak 141 kVrms, 200 kVpeak
frequency 0.01-0.1 Hz in steps of 0.01 Hz default: 0.1 Hz (auto frequency)
Rated current 1 A
HV Coupling Capacitor
capacitance ~ 1 nF 0.75 nF
dimensions (mm) L 330 x H 730 x W 280 L 330 x H 870 x W 280 L 330 x H 870 x W 280 L 660 x H 178 x W 660
weight 20.7 kg 24.7 kg 24,7 kg 90 kg
HV Filter
capacitance ~1nF 1 nF ~1nF 0.75 nF
dimensions (mm) L 300 x H 720 x W 280 L 300 x H 720 x W 280 L 300x H 820 x W 280 L 660 x H 178 x W 660
weight 19.9 kg 19.9 kg 34 kg 90 kg
Velocity range (v/2)
10-150 m/µs
Measuring range 100 km
PD background level < 10 pC
PD localization accuracy 1 %
PD resolution 0.1 pC, 0.1 m
Sample rate 200 MS/s
Bandwith 100MHz,analoglter
Signalamplication 0-52 dB (1 channel) , 0-72 dB (2 channel)
Environment
temperature: storage -20°C to + 65°C, operating -5°C to + 45°C
TAN DELTA
Output Voltage
sinusoidal 44 kV
rrns, 60 kVpeak 64 kVrms, 90 kVpeak 85 kVrms, 120 kVpeak 141 kVrms, 200 kVpeak
frequency
0.1 Hz, 0.01 to 0.1 Hz
Measuring range
0.1 x 10
-3
-999 x 10
-3
Tan Delta Measurement
resolution 1 x 10
-5
accuracy ± 1 x 10
-4
Load range 500 pF to 10 µF
1 nF to 10 µF
