3.5 Accessory (Optional)
TheseAccessoriesaren’tincludedinscopeofsupplyofthePD-Systems.Thesepositionsareonlyavailableonorder.
For enquiries please contact your local distributor or b2 electronic GmbH.
Art. No. Item Picture Art. No. Item Picture
GH0574 PD90 MC14 DUT Test Lead 100 kV TD
50 m Reel MC14
SE0010 Test adaptor 10/20 kV l=950 mm for SF6
800TRA-M16
Adaptor for 30 kVSF6 Device Coupling con-
nector Typ CC36-360 – MC 14 mm
SE0008 Test adaptor 10/20 kV l=460 mm for SF6
RSTI-68TRL
KMD0474 Corona Bell single piece
KMD0521
KMD0522
KMD0523
Corona shield two-part,
min. clearance distance = 20 mm
min. clearance distance = 25 mm
min. clearance distance = 30 mm
GH0628
GH0629
Discharge Stick 30 kV 6000 r 4 kJ
750 mm
Discharge Stick 60 kV 12 kR 8 kJ
1100 mm
