General Description
© b2 electronic GmbH DHV0088 16
3.3 Technical Specications
PD30-E PD60-2 PD90-2 PD120-2
Article number SH5027 SH5030 SH5032 SH5035
Operating voltage
sinusoidal 24 kV
rms, 34 kVpeak 44 kVrns, 60 kVpeak 64 kVrms, 90 kVpeak 85 kVrms, 120 kVpeak
frequency 0.01-0.1 Hz in steps of 0.01 Hz default: 0.1 Hz (auto frequency)
Rated current 1 A
HV coupling capacitor
capacitance ~ 1 nF
dimensions (mm) L 300 x H 486 x W 250 L 300 x H 880 x W 250 L 300 x H 880 x W 250 L 300 x H 880 x W 250
weight 29 kg 17.2 kg 21.2 kg 24.7 kg
HVlter
capacitance 4 nF ~ 1 nF 1 nF 2.4 nF
dimensions (mm) one-piece L 300 x H 720 x W 250 L 300 x H 770 x W 250 L 300x H 790 x W 250
weight one-piece 15 kg 32 kg 33 kg
Velocity range (v/2)
10-150 m/µs
Measuring range 100 km
PD background level < 10 pC
PD localization accuracy 1 %
PD resolution 0.1 pC, 0.1 m
Sample rate 200 MS/s
Bandwith 100MHz,analoglter
Signalamplication 0-52 dB (1 channel) , 0-72 dB (2 channel)
Environment
temperature: storage -20°C to + 65°C, operating -5°C to + 45°C
