3.2 Design Features
To assure that the workplace is safe and that operators can fulfil their
responsibilities with ease, the HVA28TD provides the following features.
Feature Purpose / Application Advantage
Optimized Frequency
Selection /
Automatic load
measurement
•
To test capacitive loads
• No instrument restart necessary
•
Facilitates testing
• Limits number of connections to
the DUT
Fully Automatic Test
Sequences
•
To test according to IEEE or other
standards
•
Facilitates complex testing
• Facilitates test repetition
Real Time Display
•
To indicate instantaneous output
voltage display.
•
Facilitates testing
Load independent output
•
To indicate true symmetrical
sinusoidal and square wave
waveforms output
•
Facilitates testing
Built in Memory
•
To save test sequences
• To save test reports
•
Facilitates test repetition
• Facilitates documentation
Arc Management
•
To provide short-circuit protection
• To allow for fault conditioning
•
Limits test interruptions
commonly encountered when
using conventional HV test
instruments that immediately
trip on arc detection.
Automatic load
measurement
•
To limit connections to the DUT
•
Facilitates testing
Intelligent Design
•
To avoid moving parts and need for
lubrication
•
Reduces maintenance
• Improves instrument durability
and reliability
Instrument Lock-
Key switch (7)
•
To prevent against unauthorized use
•
Improves safety
Local and remote
emergency off switches
•
To shutdown operations in
emergency situation
•
Improves safety
Fully integrated discharge
and transient circuit
•
To ground the DUT after testing
• To protect the unit from transient over
voltages
•
Improves safety
• Protects instrument
Initial load clearance test at
reduced voltages
•
To check automatically for shorts or
grounds, during load measurement,
before test initiation
•
Improves safety
Return Voltage Indication
•
To monitor external high voltage
greater than 100V (AC or DC )
•
Improves safety
Discharge Status Indication
•
To indicate when DUT is not fully
discharged.
LED Red (3) lights when residual
voltage greater than 100V
•
Improves safety during normal
disconnection procedures
USB
•
To store test reports
• To upload test sequences
•
Facilitates documentation
• Facilitates Test repetition
Bluetooth
•
To send test reports
• To upload test sequences
•
Facilitates documentation
• Facilitates Test repetition
IP67 (with closed lid)
•
To avoid damage during transport or
storage
• To protect instrument from water
•
Protects instrument
• Improves functionality
