6 Tangens Delta
© b2electronic gmbh
DHV0053 b2 EN
6.4 PC Software HVA28TD
The HVA28TD system is delivered with a set of Windows based software tools
that are packaged into a software package. This software connects, records,
analyses and reports the test results from the HVA28TD test instrument.
Description of Elements of the Main Screen:
System Information, Title Bar
The Title Bar shows connection status information like the serial of the
HVA28TD system that is paired to the current PC.
Information Selection Tabs
Use these Tabs to switch between the various information you want to view.
Phase A-C: Show detailed TD measurement information of Phase A or B or C.
If the corresponding Phase under “Currently Measured” is
selected all new measurements will automatically be inserted
under the selected tab.
Wave View: If a measurement is in progress, this tab shows a slightly delayed
real-time display of the data acquired by the TD measurement
system. Voltage and Current are shown. These values are not to
scale. The graph is updated after each finished waveform period.
Graph TD vs. Voltage:
Graphical display of the TD test results as a function of applied
voltage. The values of all three phases can be viewed and
compared. The diagram is completely auto-scaling and extracts
the mean TD value from the most recent voltage block for a
particular phase.
Current HVA28TD Value
This field shows the currently measured TD value or the last value if
measurement has stopped. Helpful if not in Phase-View, so the current TD
value can always be observed.
Report Phase Detail
Each Phase Measurement Report consists of header which includes the
HVA28TD serial number it was acquired from, and the filename that it was
stored under.
