HVA28 TD
Ultra-compact and universal
VLF High Voltage Test Set
with integrated TD Diagnostics
The b2 electronic GmbH high voltage testing and diagnostics device HVA28TD
offers outstanding features in terms of size, weight, ruggedness, safety and
ease of use. Testing and diagnostics of medium voltage cables, rotating
machines and transformers was never that easy.
Short Facts
• VLF and DC Output
• Tan Delta Diagnostics (TD)
• Sheath Test
• Sheath Fault Location
• Vacuum Bottle Test
Features
• Output voltage 28kV
peak
, 20kV
rms
• Pure sinusoidal output voltage
(load-independent)
• Output current 20mA max.
• Highest test capacity of 10µF
• Ultra light and compact weight (14kg)
• Total protection – unbreakable,
watertight, dustproof, chemical
resistant and corrosion proof case
• Protection class IP67 (with closed lid)
• Unlimited and continuous duty cycle
• Large Colour display (4,3”)
• Internal TD measurement with high
accuracy (1 x 10
-4
)
• Tan Delta measurement with various
frequency (0,01 – 0,1 Hz)
• Cable testing according:
CENELEC HD 620/621,
IEEE 400.2-2004, IEEE 400-2001, etc.
• Programmable test sequences
• USB and Bluetooth connections
• Upgradable with partial discharge
diagnostic system (optional)
• Integrated 12kV transient
protection (50Hz)
• Dual Discharge Device (DDD®),
both integrated and automatic
discharge devices
• Easy exchangeable HV cable
• Intuitive menu operation
• Sheath Test
• Sheath Fault Locating (in combination
with Earth Fault Locator)
• Vacuum Bottle Test
