WWW.BALTIMOREAIRCOIL.COM
54
Type Screen Name Description
Default
Value
Adjustable
Range Comments
Diagnostics Mode - Technician Menu Continued
M Fan Speed Manually adjust fan speed 0-100% —
V Conductivity
[1]
Conductivity of basin water (0-2000μS). Only present w/ "Water Monitoring Package" (See page 28)
[1]
M Drain Time
Duration of the periodic flush
used for bleed
120 sec TSDC
480 sec
TSDC2
0-999 sec
CAUTION: Lowering this value may result in scaling the unit. Increasing this value may result in
increased water usage
M Cycle
How far apart the periodic flush
cycles are
2 hrs 1-22 hrs NOTE: This variable is not used with the "Water Saver" Option
V Pump On Delay
Delay after float switch closes
before pump turns on
5 sec 0-20 sec —
V
Pump/Make-up
Delay
Delay after float switch opens
before pump turns off
35 sec TSDC
100 sec
TSDC2
0-999 sec —
V Make-up on Delay
Delay after float switch opens
before Make-up valve opens
30 sec TSDC
10 sec TSDC2
0-99 sec —
V Make-up off Delay
Delay after float switch closes
before Make-up valve turns off
10 sec
TSDC
30 sec TSDC2
0-999 sec
CAUTION: Increasing this value may result in increased water usage, with water spilling into the
overflow
V Pump Fail Delay
Allowable delay between pump
activation and pump proof
received before alarm trips
30 sec 0-999 sec —
V Press Fail Delay
Allowable delay between sensor
signal going above/below
acceptable range and alarm
tripping
10 sec 0-999 sec —
V Make-up Fail Delay
Allowable time for Make-up to
be on and float-switch to not
be made before alarm trips
180 sec TSDC
1,800 TSDC2
0-2,000 sec
M
High Head Pressure
Alarm Setpoint
[1]
High head pressure alarm
setpoint
500psi 0-3000psi Only present w/ 'Head Pressure' Control Option (see page 15)
[1]
M
High Head Pressure
Alarm Delay
[1]
Delay before high pressure
alarm activates
30 sec 0-999 sec Only present w/ ‘Head Pressure’ Control Option (see page 15)
[1]
M
Antifreeze protection
setpoint
Temperature below which Pre-
Cooler Mode is disabled
40°F 0-100°F
WARNING: Adjusting this value to below 35°F will void the warranty, and may cause damage to
the unit. Increasing the value will limit the wet operation.
M Gas Pressure
[1]
— — — Only present w/ ‘Head Pressure’ Control Option (see page 15)
[1]
M Gas Temperature
[1]
— — — Only present w/ ‘Head Pressure’ Control Option (see page 15)
[1]
V
Fan Power, Voltage,
Current, Motor Temp
Fan/Motor information — — —
Manual Control - Technician Menu
V Pump Proof
Check whether pump is
energized
— — —
V Float Switch
Check whether float switch
is made
— — —
M Water Pump Manually turn on/off pump — Open/Closed —
M Dump Valve
Manually turn on/off dump
valve
— Open/Closed —
M Make-up valve
Manually turn on/off make-up
valve
— Open/Closed —
V Fan Request
Fan Speed control voltage that
the controller receives from
customer analog input
—
0-10V/10-
0V/4-20mA
—
NOTE:
1. Optional features that might not be included in your unit.
2. V=Viewable, M=Modifiable, R=Read Only, and W=Read/Write.
Table 8. Complete EcoFlex™ Controls Menu Listing (Continued)
