BadgePass NXT5000 - 1-2 Printer Description and Functions

Page 5
Pushbutton
Cards and ribbon
Cleaning
Printer
Wi-Fi (option)
1-2 Description of the printer and its functions
A - Card input feeder F - Ethernet connector
B - Output hopper G - Power cable socket
C - Control panel H - Place for Kensington lock
D - USB connector (type A)
E - USB connector (type B)
C
B
A
H
G
D E
F
