BadgePass NXT5000 - Card Positioning for Smartcards

Page 59
Smartcards must be placed in the card feeder so that the chip contact is facing upwards as shown below:
1. Open the printer card feeder as shown.
2. Insert a maximum of 50 cards of thickness 0.76 mm (smartcard contact upwards). Ensure the cards are positioned as illustrated in the diagram.
3. Close the card feeder.
Card positioning
1 2 3
