GENERAL SPECIFICATIONS
FULL SCALE
HEAD RISE RANGE
0-4 inches to 0-120 inches. Maximum total range including offset distance is
132 inches.
SENSOR OFFSET Minimum distance from maximum fluid level to face of sensor is 12 inches.
OUTPUT
4-20 mADC isolated into a maximum load of 1000 ohms when operating on
AC power. Maximum load when operating on DC power depends on size of
DC voltage powering 4-20 mA loop.
Four programmable relays; SPDT 1 amp at 24 VDC/0.5 amp at 120 VAC.
DISPLAY 2 line, 24 character per line LCD display. Indicates flow rate, flow total and
alarm trip status.
PROGRAMMING Front panel mounted 5 button keypad.
POWER 115/230 VAC, 50/60 HZ, 10 watts or 12-14 VDC.
ACCURACY +/- .1% of target distance or +/- .08 inches whichever is greater. +/- 0.5% H/Q
curve reproducibility. Resolution: 0.01 inches. Repeatability: +/- 0.25%.
SENSOR Maximum cable length 1000 feet.
Temperature range: -20° F to 160° F (-30° C to 65° C).
ELECTRONIC
ENCLOSURE
NEMA 4X standard, temperature range: 32°F to 150°F (0° C to 65° C).
Optional NEMA 4X with heater and thermostat, temperatures down to -40° F
(-40° C).
