2100 SYSTEM DIAGRAM
2100 ENCLOSURE
117/220 VAC/12VDC
OUTPUTS
1/2" SEALTITE CONDUIT
& FITTINGS
2100 SENSOR
MTG BRACKET
METALLIC
CONDUIT
(PROVIDED BY
CUSTOMER)
J-BOX
(PROVIDED BY
CUSTOMER)
MAXIMUM CABLE LENGTH FROM SENSOR
TO ELECTRONICS IS 1000 FT.
SUNSHADE FOR SENSOR
(PROVIDED BY CUSTOMER)
2100
NOTE: 4-20 mA output must be in metallic conduit which does not contain any AC power,
controller/driver, or relay wiring.
1-3
