ILLUSTRATED PARTS LIST
MODEL 2100 FLOWMETER
ITEM # PART NUMBER DESCRIPTION QUANTITY
1 543198-0005 Front Housing W/Electronics 1
2 400003-0048 Screw Schcap 10-32 x 2-1/2 LG SS 4
3 501153-0001 Cap Sealing 1
501101-0001 Connector Recp 8ckts W/Sq-Flg 1
400001-0025 Screw PNH-S 4-40 x 3/8 SS 4
4A 400029-0002 Screw Hex shrh 1/4 -AB X .75 STL 2
4B 400022-0016 Screw Hex whrh 1/4-20 (ROLOK) ZN 2
5 490004 O-Ring 2
6A 151925-0001 AC Power Supply 115 VAC 1
6B 151925-0002 AC Power Supply 230 VAC 1
160978-0005 Fuse 5 x 20 mm .1A 250 V 1
7A 543198-0002 Back Housing 117 VAC 1
7B 543198-0003 Back Housing 230 VAC 1
8 512310 Gasket 1
9 543372-0001 FB1 Sensor Head W/100 Ft. cable 1
500064-0012 Sensor Cable
4-1
