DISPLAY MANUAL DP C171.UART
BUTTON DEFINITION
NORMAL OPERATION
• ON/OFF Switch
Turn on the device, press and hold
for
2s to power on the display. Press and hold
again for 2s to power off the display, If
the bike is not used, after 5 minutes (time
can be set) the display will be automatically
turned off.
• Assist Mode Selection
In the manual gearshift mode, press the
or choose the desired level of support by
the motor. The lowest level is Level 1, the
highest Level 5. When the display is on, the
default mode is Level 1. When there is no
numeric mode display, there is no power
assistance.
(power assistance lever selection interface as
below figure)
BUTTON DEFINITION
Headlight button
Switch button
Mode button
Up button
Down button
