22
BF-DM-C-DP C15-EN November 2019
7.4 DISPLAY INSTALLATION
1. Open the clamps of display and place
on to the handlebar in the correct
position.
2. Now with a M4*10 hexagon socket
screw tighten the display into position.
Torque requirement: 1N.m.
3. Now connect the Display connector to the
EB-Bus connector, ensuring both connec-
tors are kept parallel when pushing firmly
together.
To Next Page
