THE SERVICE MANUAL
Phoenix 420 440 640 642 644 650 760
Front Double 6`2” x 4`9” 6`2” x 3`7” 6`2” x 4`7” 6`2” x 4`7” 6`2” x 4`7” 6`2” x 4`7” 6`2” x 4`9”
Front nearside Single 6`1” x 2`1” 4`11” x 2`1” 5`11” x 2`1” 5`11” x 2`1” 5`11” x 2`1” 5`11” x 2`1” 6`1” x 2`1”
Front Offside Single 6`1” x 2`1” 4`11” x 2`1” 5`11” x 2`1” 5`11” x 2`1” 5`11” x 2`1” 5`11” x 2`1” 6`1” x 2`1”
Rear Fixed Bed N /A 6`3” x 4`4” 6`2” x 4`6” N/A 6`2” x 4`6” N/A N /A
Rear Offside Single N/A N/A N /A 6`2” x 2`2” N /A N /A N /A
Rear Nearside Single N /A N/A N/A 6`2” x 2`2” N /A 6`2” x 2`3” 5`10” x 2`3”
Upper Rear Bunk N/A N /A N /A N /A N/A 6`1” x 2`2” 6`1” x 2`2”
Lower Bunk N/A N/A N/A N /A N /A N /A 6`1” x 2`2”
