Bailey PHOENIX - Page 149

8
THE SERVICE MANUAL
Phoenix 420 440 640 642 644 650 760
Berths 2 4 4 4 4 5 6
Axles 1 1 1 1 1 1 2
Shipping Length 5564mm 6883mm 7370mm 7370mm 7370mm 7370mm 7864mm
Internal Length 4032mm 5351mm 5841mm 5841mm 5841mm 5841mm 6334mm
Overall Width 2212mm 2212mm 2212mm 2212mm 2212mm 2212mm 2212mm
Overall Height (including aerial) 2624mm 2624mm 2624mm 2624mm 2624mm 2624mm 2624mm
Maximum Headroom 1960mm 1960mm 1960mm 1960mm 1960mm 1960mm 1960mm
Body Length (excluding hitch) 4694mm 6013mm 6470mm 6470mm 6470mm 6470mm 6993mm
Tyre Sizes 185R14C 185R14C 185R14C 185R14C 185R14C 185R14C 185/65R14
Awning Dimension 8571mm 9860mm 10365mm 10364mm 10376mm 10376mm 10799mm
Tyre Pressure 48psi 60psi 60psi 60psi 60psi 60psi 35psi
MRO 1022kg 1166kg 1227kg 1227kg 1219kg 1223kg 1420kg
MTPLM 1139kg 1316kg 1382kg 1382kg 1374kg 1388kg 1600kg
Opt Equipment Payload 0 0 0 0 0 0 0
Total User Payload 117kg 150kg 155kg 155kg 155kg 165kg 180kg
Max Static Load on the Coupling
Head
100kg 100kg 100kg 100kg 100kg 100kg 100kg
Wheel Bolt Torque 130N 130N 130N 130N 130N 130N 130N
Gas Locker Capacity 6kg x2 6kg x2 6kg x2 6kg x2 6kg x2 6kg x2 6kg x2
3
2021 Season Amendment
Phoenix + 420 440 640 642 644 650
Berths 2 4 4 4 4 5
Axles 1 1 1 1 1 1
Shipping Length 5564mm 6883mm 7370mm 7370mm 7370mm 7370mm
Internal Length 4032mm 5351mm 5841mm 5841mm 5841mm 5841mm
Overall Width 2212mm 2212mm 2212mm 2212mm 2212mm 2212mm
Overall Height (including aerial) 2624mm 2624mm 2624mm 2624mm 2624mm 2624mm
Maximum Headroom 1960mm 1960mm 1960mm 1960mm 1960mm 1960mm
Body Length (excluding hitch) 4694mm 6013mm 6470mm 6470mm 6470mm 6470mm
Tyre Sizes 185R14C 185R14C 185R14C 185R14C 185R14C 185R14C
Awning Dimension 8571mm 9860mm 10365mm 10364mm 10376mm 10376mm
Tyre Pressure 48psi 60psi 60psi 60psi 60psi 60psi
MRO 1029kg 1197kg 1257kg 1255kg 1240kg 1244kg
MTPLM 1146kg 1347kg 1411kg 1410kg 1395kg 1409kg
Opt Equipment Payload 0 0 0 0 0 0
Total User Payload 117kg 150kg 155kg 155kg 155kg 165kg
Max Static Load on the Coupling
Head
100kg 100kg 100kg 100kg 100kg 100kg
Wheel Bolt Torque 130N 130N 130N 130N 130N 130N
Gas Locker Capacity 6kg x2 6kg x2 6kg x2 6kg x2 6kg x2 6kg x2
