Poolux System Overview
CAUTION: THE EQUIPMENT AND CONTROLS SHALL BE LOCATED NOT LESS THAN 3 METERS HORIZONTALLY
FROM THE POOL/SPA.
ATTENTION: MAINTENIR UNE DISTANCE MINIMALE, M ESUREE DANS UN PLAN HORIZONTAL, DE 3 M ENTRE
LA CUVE DE RELAXATION ET LES APPAREILS ET COMMANDES.
Fig. 1 Poolux System Overview
High Voltage Relays
Filter Pump & Aux 1 - 7
Lights #1
Service Panel
Expansion
Boxes
(4 Max)
Wireless
Transceiver
Available
Panels
Wireless
Transceiver
240 VAC
Power
Pool
Monitor/
Technician
Panel
Circuit Breaker
Subpanel
Lights #2
120V GFCI-
Protected
Dimmable
24V
Actuators
GFCI for lights
3 Aux Inputs
Dolphin RF
Water
Air
Solar
Filter Pressure Sensor
Chlorinator Cell
Pool/Spa Suction &
Return Valves 1-6
}
Temperature
Sensors
}
}
Com
Ports
(A,B,C)
pH/ORP
Conductivity
Wireless
Spa-Side
Pool Dolphin™II
Floating Remote
Note: Removable enclosure door not shown for clarity.
Dolphin RF
Receiver
Low Voltage Heater Control
Insteon
Transceiver
IMPORTANT: THE WIRELESS PANEL
MUST BE CHARGED AT THE BEGINNING
OF INSTALLATION IN ORDER FOR IT TO
BE AVAILABLE FOR CONFIGURATION.
