Start Up: Configuration Parameters
DEFAULT SETTINGS
Filter Cycles All Disabled
Chemistry
pH 7.2 to 7.8
ORP 500 to 800
TDS 1000 to 8000
Pool Set Temperature 80
°F
Spa Set Temperature 100
°F
Pool Mode Heat Disable
Spa Mode Heat Disable
Spa Filter Heat Disable
Spa Panel Button Map Light 1, Light 2
CONFIGURATION PARAMETERS
Mode: specifies which system mode the device is allowed
to operate in. Choices are Pool, Spa, and Both. Spillover
Mode is included with Pool Mode.
Device Type
: Relay, Valve, or Triac (Light 1 and 2 connectors).
Maximum Speed
: choices are Disable, On/Off, and
High/Low/Off for Relay and Valve devices; Disable, On/Off,
and High/Low/Off and Hi/Med/Low/Off for Triac devices.
For 2-speed Relay and Valve devices, Output 1 is turned on
for low speed, Output 2 for high speed. The two outputs are
never turned on together.
Output 1
: set to Internal for devices connected to the main
control board, External for devices connected to an
Expansion Box.
Expansion Boxes
: 0 for an Internal device, 1, 2, 3, or 4 to
specify an Expansion Box (# set by rotary switch in the
Expansion Box).
Device No
.: specifies which Relay, Valve, or Triac to use.
Freeze Protect
: if set to ‘Enable,’ the device will be turned
on when the air temperature drops below freezing.
Relays
: on the main control board, relays are numbered
from 1 to 10. Relay 9 is the Chlorine Generator Control
relay, and Relay 10 is the Low Voltage Heater relay. In an
Expansion Box, relays are numbered from 1 to 8.
Val ves
: valves are numbered from 1 to 6 on the main control
board, 1 and 2 in an Expansion Box. If the valve is set to
enable,” the device will be turned off whenever the suction
and return valves move.
Tria c s
: 1 is Light 1, 2 is Light 2.
Output 2, Expansion Boxes, and Device No
: these are
only used for Relay and Valve devices set to a
Maximum Speed.
Read over the Configuration Parameters to familiarize yourself with the configuration definitions and options for the
Poolux System.
DEFAULT SETTINGS
Pool Light (dimmable) Triac 1
Spa Light (dimmable) Triac 2
Filter Pump Relay 1
Heater (millivolt control) Relay 10
Aux 1 Relay 2
2 valve actuators if required
DIP Switch Configuration (see page 39)
version 6 (dual-plumbed) isn’t implemented yet
DEFAULT SETTINGS AND CONFIGURATIONS
