Balluff BIS C-300 Series User Manual

35
35
english
60
£ 60
240
226
³ 60
³ 50
106
120
4×M4
DIN 912
Distances and
Velocities between
Read/Write Head
and matching
Data carrier
Cear zone
in metal
Read /
write axis
Read/Write Head
BIS C-350-00,3
Dimensions
Standard:
Length
00,3 =0.3 m
Compatible
connection cable
2)
for adapter BIS C-670
1)
The indicated relative speeds assume a read or write of the first 4 bytes of the data carrier (bytes 0...3).
2)
BIS C-516-PU-_ _
Matching Data Carrier Static Mode (V = 0) Dynamic Mode (V > 0)
Distance [mm] Offset [mm] at a distance [mm] of Read-/
Write
range
[mm]
Distance
[mm]
Vmax. [m/min]
1)
Read Write
10 20 30 35 42 60
Read Write
non-
flush
BIS C-150-05/A 100 90 ± 30 ± 30 ± 30 126/140 63/70 120 75
BIS C-150-11/A 100 90 ± 30 ± 30 ± 30 126/140 63/70 120 75
BIS C-150-32/A 100 90 ± 30 ± 30 ± 30 126/140 63/70 120 75
C3-slk_716464_E_1110.p65
36
english36
60
£ 60
240
226
³ 60
³ 50
106
120
4×M4
DIN 912
Read/Write Head
BIS C-355/05-S92
Dimensions
Standard:
Length
05 = 5 m
= Compatible
connection cable
2)
with 5 m length
1)
The indicated relative speeds assume a read or write of the first 4 bytes of the data carrier (bytes 0...3).
2)
BIS C-520-PVC-05
Matching Data Carrier Static Mode (V = 0) Dynamic Mode (V > 0)
Distance [mm] Offset [mm] at a distance [mm] of Read-/
Write
range
[mm]
Distance
[mm]
Vmax. [m/min]
1)
Read Write 10 20 30 35 42 Read Write
non-
flush
BIS C-150-05/A 0 to 40 0 to 35 ± 15 ± 5 260 1 to 35 220 150
BIS C-150-11/A 0 to 40 0 to 35 ± 15 ± 5 260 1 to 35 220 150
BIS C-150-32/A 0 to 40 0 to 35 ± 15 ± 5 260 1 to 35 220 150
Clear zone
in metal
For special
requirements!
Using bar/double
antenna for increased
traverse speed
Distances and
Velocities between
Read/Write Head
and matching
Data carrier
Read /
write axis
