Display and connection housing
rotate 320°
Fig. 5: Dimensional drawing of standard and high-end pressure sensors, not flush-mounted
Process connection
per EN 3852
Installation (continued)
Fig. 6: Dimensional drawing of flush-mounted pressure sensors, up to 50 bar
Fig. 7: Dimensional drawing of flush-mounted pressure sensors, starting at 100 bar
Process connection
per EN 3852
Display and connection housing rotate 320°
Process connection per EN 3852
Display and connection housing rotate 320°
