4 English
Adapter for process connection
BSP pressure sensors can be adapted to different process
connections using adapters (accessories) available as an
optional extra. The adapters must be ordered separately.
Adapters for other process connections are available on
request.
Adapter G 1/4" per EN 3852
Ordering code: BAM01KP
Stainless steel
Connection:
– Sensor end: G 1/4"
– Process end: G 1/4"
Torque approx. 5 Nm
Installation (continued)
Adapter NPT 1/4"
Ordering code: BAM01KT
Stainless steel
Connection:
– Sensor end: G 1/4"
– Process end: NPT 1/4"
Torque approx. 30 Nm
Adapter G 1/4" per EN 837
for attachment to pressure
gauge
Ordering code: BAM01KR
Stainless steel
Connection:
– Sensor end: G 1/4"
– Process end: G 1/4"
Torque approx. 20 Nm
Adapter R 1/4"
Ordering code: BAM01RP
Stainless steel
Connection:
– Sensor end: G 1/4"
– Process end: R 1/4"
Torque approx. 30 Nm
Adapter NPT 1/4"
Ordering code: BAM01TR
Stainless steel
Connection:
– Sensor end: G 1/4" per
DIN EN 3852
– Process end: NPT 1/4"
Torque approx. 30 Nm
Adapter G 1/2"
Ordering code: BAM01UJ
Stainless steel
Connection:
– Sensor end: G 1/4" per
DIN EN 3852
– Process end: G 1/2" per
DIN EN 3852
Torque approx. 30 Nm
Adapter M20x1.5
Ordering cod: BAM0209
Stainless steel
Connection:
– Sensor end: G 1/4" per
DIN EN 3852
– Process end: M20x1.5
Torque approx. 30 Nm
Pressure Sensors with IO-Link
BSP-B... /-V...
